Description
Sifam Tinsley Synchroscopes are designed to provide an illuminated indication of actual phase difference between the BUS Voltage(reference voltage) & the GENERATOR Voltage(incoming voltage).
It denotes the actual frequency difference corresponding to the inverse of time taken for one rotation of the illuminated vector spot. When two alternators are paralleled, it is necessary that, 1) Frequency must be equal and 2) {jase ,ist be the same.. Sychroscope is, hence used to indicate the Phase & Frequency difference between two AC alternators, which are to be paralleled.
The rotation of the vector spot is with reference to the bus voltage. If the vector spot LED turns clockwise,it indicates the GENERATOR frequency is greater than the BUS frequency. It means the speed of the generator must be reduced by the operator. If the spot LED turns anticlockwise,the GENERATOR frequency is less than BUS frequency.In this case speed of the generator must be increased.
- Rotating LEDs indicate frequency & phase difference between generator & bus voltages
- Green SYNC LEDs indicate frequency & phase match
| Item # | Input Voltage | Size | P/N | Minimum Order | Ship From Country |
|---|---|---|---|---|---|
| SQ94-V02XXNXWAW0ST | 100V or 127V | 96x96mm | SQ94-V02XXNXWAW0ST | 1 | US |
| SQ94-V12XXNXWAW0ST | 480V or 415V | 96x96mm | SQ94-V12XXNXWAW0ST | 1 | US |
| SQ94-V03XXNXWAW0ST | 110V or 100V | 96x96mm | SQ94-V03XXNXWAW0ST | 1 | US |
| SQ94-V08XXNXWAW0ST | 400V | 96x96mm | SQ94-V08XXNXWAW0ST | 1 | US |
| SQ94-V05XXNXWAW0ST | 240V or 220V | 96x96mm | SQ94-V05XXNXWAW0ST | 1 | US |
| SQ94-V13XXNXWAW0ST | 57.8V | 96x96mm | SQ94-V13XXNXWAW0ST | 1 | US |
| SQ94-V04XXNXWAW0ST | 127V or 120V | 96x96mm | SQ94-V04XXNXWAW0ST | 1 | US |
| SQ94-V14XXNXWAW0ST | 63.5V | 96x96mm | SQ94-V14XXNXWAW0ST | 1 | US |
| SQ94-V06XXNXWAW0ST | 380V or 415V | 96x96mm | SQ94-V06XXNXWAW0ST | 1 | US |
| SQ14-V01XXNXWAW0ST | 100V or 120V | 144x144mm | SQ14-V01XXNXWAW0ST | 1 | US |
| SQ94-V07XXNXWAW0ST | 380V or 440V | 96x96mm | SQ94-V07XXNXWAW0ST | 1 | US |
| SQ14-V02XXNXWAW0ST | 100V or 127V | 144x144mm | SQ14-V02XXNXWAW0ST | 1 | US |
| SQ14-V03XXNXWAW0ST | 110V or 100V | 144x144mm | SQ14-V03XXNXWAW0ST | 1 | US |
| SQ14-V04XXNXWAW0ST | 127V or 120V | 144x144mm | SQ14-V04XXNXWAW0ST | 1 | US |
| SQ14-V05XXNXWAW0ST | 240V or 220V | 144x144mm | SQ14-V05XXNXWAW0ST | 1 | US |
| SQ14-V06XXNXWAW0ST | 380V or 415V | 144x144mm | SQ14-V06XXNXWAW0ST | 1 | US |
| SQ14-V07XXNXWAW0ST | 380V or 440V | 144x144mm | SQ14-V07XXNXWAW0ST | 1 | US |
| SQ14-V08XXNXWAW0ST | 400V | 144x144mm | SQ14-V08XXNXWAW0ST | 1 | US |
| SQ14-V14XXNXWAW0ST | 63.5V | 144x144mm | SQ14-V14XXNXWAW0ST | 1 | US |
| SQ14-V13XXNXWAW0ST | 57.8V | 144x144mm | SQ14-V13XXNXWAW0ST | 1 | US |
| SQ14-V12XXNXWAW0ST | 480V or 415V | 144x144mm | SQ14-V12XXNXWAW0ST | 1 | US |
