250° DC Meters – 250 Series – Hoyt

Description

Hoyt Analog Panel Meters 250 Series – Ideal for harsh conditions where vibration is a concern. Utilize a highly damped, spring loaded pivot and jewel movement with mechanical interlocking to develop high torque. The meters are desirable for the following applications: Emergency Vehicles, Marine Instrumentation, Speed (RPM), Pressure and Flow, Pyrometers, ­ Diesel and Gas Instrumentations.

The Hoyt 250° meters utilize a highly damped, spring loaded pivot and jewel movement; mechanically interlocked, negating the use of adhesives and develops a very high torque. The meters are desirable for the following applications:

  • Emergency Vehicles
  • Marine Instrumentation
  • Speed (RPM)
  • Pressure and Flow
  • Pyrometers
  • Diesel and Gas Instrumentations

Features

  • 2″, 3″ and 3-3/8″ Sizes
  • Special ranges and resistances to match your equipment design.
  • Electrical damping to control overshoot and oscillation.
  • Optional custom dials with your name, logo, etc.
  • Long 250 degree pointer swing.
  • Pivot and jewel movement.
  • Now available with or without illumination.
  • Available with chrome or black bezels.
  • 1 year limited warranty.
  • High impact metal case.
  • Color fast metal dials.
  • DC moving coil movement.
  • 1% & 2% accuracy available.

Catalog Page 073                       Hoyt-250Series-DS
