Yokogawa 286 Edgewise Panel Meter – Replacements
Description
The H6286 Series are 1-1*2” meters designed to handle applications where panel space is at a premium. They can be mounted horizontally or vertically and meet ANSI C39.1. Unlike most edgewise meters, the H6286 series provides an accuracy of ±2% of full scale in DC and ±3% for AC.
The thin element design still provides the maximum performance in the smallest of spaces. They can stand alone or be stacked in space-saving clusters. Built-in magnetic shielding prevents interference among meters and removes the burden of special calibration.
Replacements for Yokogawa 286 Edgewise Panel Meters
- Pointer Color: Red standard.
- Overshoot: 25% (max.).
- Scale data: 53° deflection.
- Accuracy: ±2% of full scale, DC meters. ±3% with 60 Hz sine wave at 25°C for AC rectifier type meters.
- Dielectric: (Hi-pot): 1500 VRMS.
- Response Time: 3 seconds max for uA meters, 2 seconds (max.) for mA, A, mV, and V meters.
- Available with Horizontal or Vertical scales.
- Bezel and Mounting Hardware: Included with meter.
- Made in the USA.
- Warranty: 1 Year
Show Advanced Filters
products found
Item # | Yokogawa PN | Type | Range | Standard Scale |
---|---|---|---|---|
H6286011MTMT | 286011MTMT | DC Voltmeter | 10 VDC | 0-10 DC Volts |
H6286011NDND | 286011NDND | DC Voltmeter | 15 VDC | 0-15 DC Volts |
H6286011NLNL | 286011NLNL | DC Voltmeter | 30 VDC | 0-30 DC Volts |
H6286011NTNT | 286011NTNT | DC Voltmeter | 50 VDC | 0-50 DC Volts |
H6286011PKPK | 286011PKPK | DC Voltmeter | 100 VDC | 0-100 DC Volts |
H6286011PZPZ | 286011PZPZ | DC Voltmeter | 150 VDC | 0-150 DC Volts |
H6286012NDND | 286012NDND | DC Voltmeter - Zero Center | 15-0-15 VDC | 15-0-15 DC Volts |
H6286012NLNL | 286012NLNL | DC Voltmeter - Zero Center | 30-0-30 VDC | 30-0-30 DC Volts |
H6286171FASF | 286171FASF | DC Voltmeter - Ext Resistor | 1 mADC | 0-500 DC Volts |
H6286171FASJ | 286171FASJ | DC Voltmeter - Ext Resistor | 1 mADC | 0-600 DC Volts |
H6286171FASM | 286171FASM | DC Voltmeter - Ext Resistor | 1 mADC | 0-750 DC Volts |
H6286111CYCY | 286111CYCY | DC Microammeter | 50 uADC | 0-50 DC Microamperes |
H6286111DRDR | 286111DRDR | DC Microammeter | 100 uADC | 0-100 DC Microamperes |
H6286111EAEA | 286111EAEA | DC Microammeter | 200 uADC | 0-200 DC Microamperes |
H6286111EMEM | 286111EMEM | DC Microammeter | 500 uADC | 0-500 DC Microamperes |
H6286111FAFA | 286111FAFA | DC Milliammeter | 1 mADC | 0-1 DC Milliamperes |
H6286111FXFX | 286111FXFX | DC Milliammeter | 5 mADC | 0-5 DC Milliamperes |
H6286111GZGZ | 286111GZGZ | DC Milliammeter | 10 mADC | 0-10 DC Milliamperes |
H6286111HJHJ | 286111HJHJ | DC Milliammeter | 25 mADC | 0-25 DC Milliamperes |
H6286111HYHY | 286111HYHY | DC Milliammeter | 50 mADC | 0-50 DC Milliamperes |
H6286111JRJR | 286111JRJR | DC Milliammeter | 100 mADC | 0-100 DC Milliamperes |
H6286111KDKD | 286111KDKD | DC Milliammeter | 250 mADC | 0-250 DC Milliamperes |
H6286111KMKM | 286111KMKM | DC Milliammeter | 500 mADC | 0-500 DC Milliamperes |
H6286111LALA | 286111LALA | DC Ammeter - Self-Contained | 1 ADC | 0-1 DC Amperes |
H6286111LCLC | 286111LCLC | DC Ammeter - Self-Contained | 1.5 ADC | 0-1.5 DC Amperes |
H6286111LELE | 286111LELE | DC Ammeter - Self-Contained | 2 ADC | 0-2 DC Amperes |
H6286111LJLJ | 286111LJLJ | DC Ammeter - Self-Contained | 3 ADC | 0-3 DC Amperes |
H6286111LSLS | 286111LSLS | DC Ammeter - Self-Contained | 5 ADC | 0-5 DC Amperes |
H6286112CYCY | 286112CYCY | DC Microammeter - Zero Center | 50-0-50 uADC | 50-0-50 DC Microamperes |
H6286112DRDR | 286112DRDR | DC Microammeter - Zero Center | 100-0-100 uADC | 100-0-100 DC Microamperes |
H6286112EMEM | 286112EMEM | DC Microammeter - Zero Center | 500-0-500 uADC | 500-0-500 DC Microamperes |
H6286112FAFA | 286112FAFA | DC Milliammeter - Zero Center | 1-0-1 mADC | 1-0-1 DC Milliamperes |
H6286112FXFX | 286112FXFX | DC Milliammeter - Zero Center | 5-0-5 mADC | 5-0-5 DC Milliamperes |
H6286112LSLS | 286112LSLS | DC Milliammeter - Zero Center | 5-0-5 ADC | 5-0-5 DC Milliamperes |
H6286121ECLA | 286121ECLA | DC Ammeter - Shunt Rated | 50 mVDC | 0-1 DC Amperes |
H6286121ECLS | 286121ECLS | DC Ammeter - Shunt Rated | 50 mVDC | 0-5 DC Amperes |
H6286121ECMT | 286121ECMT | DC Ammeter - Shunt Rated | 50 mVDC | 0-10 DC Amperes |
H6286121ECNG | 286121ECNG | DC Ammeter - Shunt Rated | 50 mVDC | 0-20 DC Amperes |
H6286121ECNT | 286121ECNT | DC Ammeter - Shunt Rated | 50 mVDC | 0-50 DC Amperes |
H6286121ECRX | 286121ECRX | DC Ammeter - Shunt Rated | 50 mVDC | 0-300 DC Amperes |
H6286121ECSF | 286121ECSF | DC Ammeter - Shunt Rated | 50 mVDC | 0-500 DC Amperes |
H6286051MTMT | 286051MTMT | AC Voltmeter | 10 VAC | 0-10 AC Volts |
H6286051NDND | 286051NDND | AC Voltmeter | 15 VAC | 0-15 AC Volts |
H6286051NLNL | 286051NLNL | AC Voltmeter | 30 VAC | 0-30 AC Volts |
H6286051NTNT | 286051NTNT | AC Voltmeter | 50 VAC | 0-50 AC Volts |
H6286051PKPK | 286051PKPK | AC Voltmeter | 100 VAC | 0-100 AC Volts |
H6286051PZPZ | 286051PZPZ | AC Voltmeter | 150 VAC | 0-150 AC Volts |
H6286151FAFA | 286151FAFA | AC Milliammeter | 1 mAAC | 0-1 AC Milliamperes |
H6286151FXFX | 286151FXFX | AC Milliammeter | 5 mAAC | 0-5 AC Milliamperes |
H6286151GZGZ | 286151GZGZ | AC Milliammeter | 10 mAAC | 0-10 AC Milliamperes |
H6286151HFHF | 286151HFHF | AC Milliammeter | 20 mAAC | 0-20 AC Milliamperes |
H6286013MTMT | 286013MTMT | DC Voltmeter | 10 VDC | 0-10 DC Volts |
H6286013NDND | 286013NDND | DC Voltmeter | 15 VDC | 0-15 DC Volts |
H6286013NLNL | 286013NLNL | DC Voltmeter | 30 VDC | 0-30 DC Volts |
H6286013NTNT | 286013NTNT | DC Voltmeter | 50 VDC | 0-50 DC Volts |
H6286013PKPK | 286013PKPK | DC Voltmeter | 100 VDC | 0-100 DC Volts |
H6286013PZPZ | 286013PZPZ | DC Voltmeter | 150 VDC | 0-150 DC Volts |
H6286014NDND | 286014NDND | DC Voltmeter - Zero Center | 15-0-15 VDC | 15-0-15 DC Volts |
H6286014NLNL | 286014NLNL | DC Voltmeter - Zero Center | 30-0-30 VDC | 30-0-30 DC Volts |
H6286173FASF | 286173FASF | DC Voltmeter - Ext Resistor | 1 mADC | 0-500 DC Volts |
H6286173FASJ | 286173FASJ | DC Voltmeter - Ext Resistor | 1 mADC | 0-600 DC Volts |
H6286173FASM | 286173FASM | DC Voltmeter - Ext Resistor | 1 mADC | 0-750 DC Volts |
H6286113CYCY | 286113CYCY | DC Microammeter | 50 uADC | 0-50 DC Microamperes |
H6286113DRDR | 286113DRDR | DC Microammeter | 100 uADC | 0-100 DC Microamperes |
H6286113EAEA | 286113EAEA | DC Microammeter | 200 uADC | 0-200 DC Microamperes |
H6286113EMEM | 286113EMEM | DC Microammeter | 500 uADC | 0-500 DC Microamperes |
H6286113FAFA | 286113FAFA | DC Milliammeter | 1 mADC | 0-1 DC Milliamperes |
H6286113FXFX | 286113FXFX | DC Milliammeter | 5 mADC | 0-5 DC Milliamperes |
H6286113GZGZ | 286113GZGZ | DC Milliammeter | 10 mADC | 0-10 DC Milliamperes |
H6286113HJHJ | 286113HJHJ | DC Milliammeter | 25 mADC | 0-25 DC Milliamperes |
H6286113HYHY | 286113HYHY | DC Milliammeter | 50 mADC | 0-50 DC Milliamperes |
H6286113JRJR | 286113JRJR | DC Milliammeter | 100 mADC | 0-100 DC Milliamperes |
H6286113KDKD | 286113KDKD | DC Milliammeter | 250 mADC | 0-250 DC Milliamperes |
H6286113KMKM | 286113KMKM | DC Milliammeter | 500 mADC | 0-500 DC Milliamperes |
H6286113LALA | 286113LALA | DC Ammeter - Self-Contained | 1 ADC | 0-1 DC Amperes |
H6286113LCLC | 286113LCLC | DC Ammeter - Self-Contained | 1.5 ADC | 0-1.5 DC Amperes |
H6286113LELE | 286113LELE | DC Ammeter - Self-Contained | 2 ADC | 0-2 DC Amperes |
H6286113LJLJ | 286113LJLJ | DC Ammeter - Self-Contained | 3 ADC | 0-3 DC Amperes |
H6286113LSLS | 286113LSLS | DC Ammeter - Self-Contained | 5 ADC | 0-5 DC Amperes |
H6286114CYCY | 286114CYCY | DC Microammeter - Zero Center | 50-0-50 uADC | 50-0-50 DC Microamperes |
H6286114DRDR | 286114DRDR | DC Microammeter - Zero Center | 100-0-100 uADC | 100-0-100 DC Microamperes |
H6286114EMEM | 286114EMEM | DC Microammeter - Zero Center | 500-0-500 uADC | 500-0-500 DC Microamperes |
H6286114FAFA | 286114FAFA | DC Milliammeter - Zero Center | 1-0-1 mADC | 1-0-1 DC Milliamperes |
H6286114FXFX | 286114FXFX | DC Milliammeter - Zero Center | 5-0-5 mADC | 5-0-5 DC Milliamperes |
H6286114LSLS | 286114LSLS | DC Milliammeter - Zero Center | 5-0-5 ADC | 5-0-5 DC Milliamperes |
H6286123ECLA | 286123ECLA | DC Ammeter - Shunt Rated | 50 mVDC | 0-1 DC Amperes |
H6286123ECLS | 286123ECLS | DC Ammeter - Shunt Rated | 50 mVDC | 0-5 DC Amperes |
H6286123ECMT | 286123ECMT | DC Ammeter - Shunt Rated | 50 mVDC | 0-10 DC Amperes |
H6286123ECNG | 286123ECNG | DC Ammeter - Shunt Rated | 50 mVDC | 0-20 DC Amperes |
H6286123ECNT | 286123ECNT | DC Ammeter - Shunt Rated | 50 mVDC | 0-50 DC Amperes |
H6286123ECRX | 286123ECRX | DC Ammeter - Shunt Rated | 50 mVDC | 0-300 DC Amperes |
H6286123ECSF | 286123ECSF | DC Ammeter - Shunt Rated | 50 mVDC | 0-500 DC Amperes |
H6286053MTMT | 286053MTMT | AC Voltmeter | 10 VAC | 0-10 AC Volts |
H6286053NDND | 286053NDND | AC Voltmeter | 15 VAC | 0-15 AC Volts |
H6286053NLNL | 286053NLNL | AC Voltmeter | 30 VAC | 0-30 AC Volts |
H6286053NTNT | 286053NTNT | AC Voltmeter | 50 VAC | 0-50 AC Volts |
H6286053PKPK | 286053PKPK | AC Voltmeter | 100 VAC | 0-100 AC Volts |
H6286053PZPZ | 286053PZPZ | AC Voltmeter | 150 VAC | 0-150 AC Volts |
H6286153FAFA | 286153FAFA | AC Milliammeter | 1 mAAC | 0-1 AC Milliamperes |
H6286153FXFX | 286153FXFX | AC Milliammeter | 5 mAAC | 0-5 AC Milliamperes |
H6286153GZGZ | 286153GZGZ | AC Milliammeter | 10 mAAC | 0-10 AC Milliamperes |
H6286153HFHF | 286153HFHF | AC Milliammeter | 20 mAAC | 0-20 AC Milliamperes |
