Wireless Digital Phasing Testers – Bierer Meters

Description

The PD800W Cordless Phasing Tester accurately and easily operates in multiple applications including phasing, voltage detection, phase sequencing and phase angle indication. One kit rapidly tests three-phase secondary systems, capacitive test points, URD systems as well as overhead and transmission/substation systems. This unique tester operates like a conventional phasing tester but does not require an interconnecting cable or extension resistors. Each probe is water-resistant, designed to withstand wear and is completely shielded to minimize stray field interference. Both the Reference Probe and the Meter Probe have a five-position selector switch that controls different operating modes.

  •  Large easy-to-read digital display with backlight
  •  High-intensity color-coded LED phase indicators
  •  Requires no interconnecting cable
  •  Operating range of 100ft
  •  Direct contact phasing from 120V – 69kV
  • Non-contact phasing from 69kV – 800kV
  •  Shows phase angle relationship in degrees
  •  Direct contact voltage from 4kV – 69kV
  •  Automatically alerts for Delta/Wye transformation

Catalog-Page-172b                           Bierer_Brochure

This product is currently out of stock and unavailable.


products found
Item # Ordering Information
BR/PD800W120 volt – 800,000 volt Cordless Phasing Tester, hook probe, straight probe, universal/grip-all adapter, manual, case
BR/PD8H2W120 volt – 800,000 volt Cordless Phasing Tester, 2ft. transmission hook, hook probe, straight probe, universal/grip-all adapter, manual, 26 case
