Simpson Elapsed Time Meters

Description

Each true-time elapsed time meter is ruggedly constructed and is widely used in factory environments where there is a need to accumulate running time and monitor life and performance records on AC and DC powered equipment. All hour meters are connected in parallel with the equipment being monitored. The synchronous motor provides accurate hour indication (to 99,999.9 hours)

  • 6 Digit Readout
  • No Reset Capability (Virtually Tamper-proof)
  • Six Case Styles
  • 1½” and 3½” sizes
  • AC and DC Models
  • Phenolic cases with glass windows



Catalog Page 127                                           Elapsedtime-Datasheet

This product is currently out of stock and unavailable.

SKU: N/A Categories: ,
Show Advanced Filters

products found
Item # Model Voltage Size Maximum Indication (hours)
SI/03622112ET120 VAC1-1/2"99,999.9
SI/03618109ET10-80 VDC1-1/2"999,999.9
SI/177202153ET120 VAC3-1/2"99,999.9
SI/0358055ET120 VAC3-1/2"99,999.9
SI/035951357ET120 VAC3-1/2"99,999.9
SI/0360055ET240 VAC3-1/2"99,999.9
SI/0361057ET240 VAC3-1/2"99,999.9
SI/177212153ET240 VAC3-1/2"99,999.9
SI/0359057ET120 VAC3-1/2"99,999.9
SI/036151357ET240 VAC3-1/2"99,999.9
