Megger TC3231 Thermal Camera (-4 to +572°F)

Description

The Megger TC3231 offers a professional infrared 32 x 31 pixels image thermometer with a 2.2 inch (55.88 mm) color TFT LCD display. Quick, accurate readings are possible; covering a wide range of surface temperature measurements. For convenience, background temperature is also user selectable

The product combines the convenience of an infrared thermometer with the visual advantage of a thermal imager providing a troubleshooting camera with an infrared heat map. The TC3231 features a range of selectable thermal image color palette display options along with high/low user preset temperature alarms.

An easy to use image blending function is also featured; the camera takes an aligned visible, non-infrared, image, together with a full infrared image. The 2 pictures are then blended and can be adjusted between 0 to 100%. This makes identifying problems and pinpointing their location far easier.

As well as center spot temperature measurement, the camera also offers simultaneous hot and cold spot tracking, with resultant values and location updated continuously on the display.

Up to 6000 images can be saved on the included micro SD memory card which can be downloaded to a PC via the USB interface in BMP file format. An SD card adapter is also provided for file transfer directly to a computer if required.

Features

  • 2.2 inch (55.88 mm) 320*240 TFT LCD display
  • 32 x 31 pixel resolution IR temperature measurement
  • Measurement range (-20 ° to 300 °C)  / (-4 °F to 572 °F)
  • Adjustable emissivity
  • Micro SD memory for storing up to 6000 images
  • High & Low Alarm (enable & disable)
  • Selectable colour palette
  • Image blending with selectable distance of 0.5 m, 1 m, 2 m or 3 m



Specifications

Thermal Camera Specs



Thermal Camera

Megger TC3231 Comes Supplied With:

  • TC3231 Thermal Camera
  • USB Interface
  • Mains adapter
  • SD Card
  • Tripod
  • User Instructions
  • Calibration Certificate

TC3231_Datasheet

Clear
SKU: N/A Categories: ,

products found
Item # Description Price
1012-514TC3231 Thermal Camera (-4-572°F)$515.00
