London Electronics DC Loop Powered Meters

Description

The London Electronics 88-PRO is a low-cost, 3½-digit, scalable, process input indicator. It has an easy-to-read LCD display and detachable screw terminals. The basic 3½-digit offers 0 to 1,999 display range. This can be extended to 0 to 199,900 with both add-on zeroes enabled.It can display a wide range of process variables such as temperature, pressure, flow, weight, pH, humidity etx. It accepts 4-20mA, 10-50mA and 1-5mA inputs.

  • Powered Entirely from the Input Signal
  • High Contrast LCD Display
  • Clear Visibility in Direct Sunlight
  • 1/8 DIN Case
  • Detachable Screw Terminal Connectors
  • Wide Ranging Zero and Span Control
  • Selectable Decimal Point Location
  • Simple to Install
  • Low Cost
  • X10 and X100 Add-On Zeros (Jumper Selectable)



Catalog Page 37a                               88pro-Datasheet

This product is currently out of stock and unavailable.


products found
Item # Configuration
88-PRO3 1/2-Digit Loop Powered Meter
Sorry, no products were found fitting that criteria. Please widen your search or reset item filters now
