Challenger series DC Voltmeters – Crompton

Description

The Challenger range of analog panel meters offers accurate measurement and indication of most electrical and electronic parameters in industry standard 1½”, 2½”, 3½” and 4½” case sizes. This innovative design features a detachable lower fascia plate, which allows the flexibility of either surface or window mounting. The fascia is simply unclipped to achieve the completely flush panel appearance of rear of panel window mounting.

These meters utilize a high torque pivot and jewel movement.

  • Accuracy: ±2% of Full Scale
  • Meets ANSI C39.1
  • Four Display Sizes: 1½”, 2½”, 3½”, and 4½”
  • Pivot & Jewel Movement
  • Replacements for Yokogawa Horizon and Stylist series

Catalog Page 59a                                   Crompton-Challenger-new



Clear
Show Advanced Filters

products found
Item # Model Case Size Range Scale Size (HxWxD)
364-01NA-PDPDChallenger - DC Voltmeter - Zero Center4-1/280-0-80 Volts80-0-80 Volts4.18 x 4.73 x 1.83
361-01VA-LALAChallenger - DC Voltmeter1-1/21 Volts1 Volts1.8 x 2.3 x 1.8
362-01VA-LALAChallenger - DC Voltmeter2-1/21 Volts1 Volts2.66 x 3.12 x 1.81
363-01VA-LALAChallenger - DC Voltmeter3-1/21 Volts1 Volts3.32 x 3.89 x 1.83
364-01VA-LALAChallenger - DC Voltmeter4-1/21 Volts1 Volts4.18 x 4.73 x 1.83
361-01VA-LCLCChallenger - DC Voltmeter1-1/21.5 Volts1.5 Volts1.8 x 2.3 x 1.8
362-01VA-LCLCChallenger - DC Voltmeter2-1/21.5 Volts1.5 Volts2.66 x 3.12 x 1.81
363-01VA-LCLCChallenger - DC Voltmeter3-1/21.5 Volts1.5 Volts3.32 x 3.89 x 1.83
364-01VA-LCLCChallenger - DC Voltmeter4-1/21.5 Volts1.5 Volts4.18 x 4.73 x 1.83
361-01VA-MTMTChallenger - DC Voltmeter1-1/210 Volts10 Volts1.8 x 2.3 x 1.8
362-01VA-MTMTChallenger - DC Voltmeter2-1/210 Volts10 Volts2.66 x 3.12 x 1.81
363-01VA-MTMTChallenger - DC Voltmeter3-1/210 Volts10 Volts3.32 x 3.89 x 1.83
364-01VA-MTMTChallenger - DC Voltmeter4-1/210 Volts10 Volts4.18 x 4.73 x 1.83
361-01VA-JRJRChallenger - DC Millivoltmeter1-1/2100 mV100 mV1.8 x 2.3 x 1.8
362-01VA-JRJRChallenger - DC Millivoltmeter2-1/2100 mV100 mV2.66 x 3.12 x 1.81
363-01VA-JRJRChallenger - DC Millivoltmeter3-1/2100 mV100 mV3.32 x 3.89 x 1.83
364-01VA-JRJRChallenger - DC Millivoltmeter4-1/2100 mV100 mV4.18 x 4.73 x 1.83
361-01VA-PKPKChallenger - DC Voltmeter1-1/2100 Volts100 Volts1.8 x 2.3 x 1.8
362-01VA-PKPKChallenger - DC Voltmeter2-1/2100 Volts100 Volts2.66 x 3.12 x 1.81
363-01VA-PKPKChallenger - DC Voltmeter3-1/2100 Volts100 Volts3.32 x 3.89 x 1.83
364-01VA-PKPKChallenger - DC Voltmeter4-1/2100 Volts100 Volts4.18 x 4.73 x 1.83
361-01NA-MTMTChallenger - DC Voltmeter - Zero Center1-1/210-0-10 Volts10-0-10 Volts1.8 x 2.3 x 1.8
362-01NA-MTMTChallenger - DC Voltmeter - Zero Center2-1/210-0-10 Volts10-0-10 Volts2.66 x 3.12 x 1.81
363-01NA-MTMTChallenger - DC Voltmeter - Zero Center3-1/210-0-10 Volts10-0-10 Volts3.32 x 3.89 x 1.83
364-01NA-MTMTChallenger - DC Voltmeter - Zero Center4-1/210-0-10 Volts10-0-10 Volts4.18 x 4.73 x 1.83
361-01VA-PQPQChallenger - DC Voltmeter1-1/2120 Volts120 Volts1.8 x 2.3 x 1.8
362-01VA-PQPQChallenger - DC Voltmeter2-1/2120 Volts120 Volts2.66 x 3.12 x 1.81
363-01VA-PQPQChallenger - DC Voltmeter3-1/2120 Volts120 Volts3.32 x 3.89 x 1.83
364-01VA-PQPQChallenger - DC Voltmeter4-1/2120 Volts120 Volts4.18 x 4.73 x 1.83
361-01VA-NDNDChallenger - DC Voltmeter1-1/215 Volts15 Volts1.8 x 2.3 x 1.8
362-01VA-NDNDChallenger - DC Voltmeter2-1/215 Volts15 Volts2.66 x 3.12 x 1.81
363-01VA-NDNDChallenger - DC Voltmeter3-1/215 Volts15 Volts3.32 x 3.89 x 1.83
364-01VA-NDNDChallenger - DC Voltmeter4-1/215 Volts15 Volts4.18 x 4.73 x 1.83
361-01VA-JXJXChallenger - DC Millivoltmeter1-1/2150 mV150 mV1.8 x 2.3 x 1.8
362-01VA-JXJXChallenger - DC Millivoltmeter2-1/2150 mV150 mV2.66 x 3.12 x 1.81
363-01VA-JXJXChallenger - DC Millivoltmeter3-1/2150 mV150 mV3.32 x 3.89 x 1.83
364-01VA-JXJXChallenger - DC Millivoltmeter4-1/2150 mV150 mV4.18 x 4.73 x 1.83
361-01VA-PZPZChallenger - DC Voltmeter1-1/2150 Volts150 Volts1.8 x 2.3 x 1.8
362-01VA-PZPZChallenger - DC Voltmeter2-1/2150 Volts150 Volts2.66 x 3.12 x 1.81
363-01VA-PZPZChallenger - DC Voltmeter3-1/2150 Volts150 Volts3.32 x 3.89 x 1.83
364-01VA-PZPZChallenger - DC Voltmeter4-1/2150 Volts150 Volts4.18 x 4.73 x 1.83
361-01NA-PZPZChallenger - DC Voltmeter - Zero Center1-1/2150-0-150 V150-0-150 V1.8 x 2.3 x 1.8
362-01NA-PZPZChallenger - DC Voltmeter - Zero Center2-1/2150-0-150 V150-0-150 V2.66 x 3.12 x 1.81
363-01NA-PZPZChallenger - DC Voltmeter - Zero Center3-1/2150-0-150 V150-0-150 V3.32 x 3.89 x 1.83
364-01NA-PZPZChallenger - DC Voltmeter - Zero Center4-1/2150-0-150 V150-0-150 V4.18 x 4.73 x 1.83
361-01NA-NDNDChallenger - DC Voltmeter - Zero Center1-1/215-0-15 Volts15-0-15 Volts1.8 x 2.3 x 1.8
362-01NA-NDNDChallenger - DC Voltmeter - Zero Center2-1/215-0-15 Volts15-0-15 Volts2.66 x 3.12 x 1.81
363-01NA-NDNDChallenger - DC Voltmeter - Zero Center3-1/215-0-15 Volts15-0-15 Volts3.32 x 3.89 x 1.83
364-01NA-NDNDChallenger - DC Voltmeter - Zero Center4-1/215-0-15 Volts15-0-15 Volts4.18 x 4.73 x 1.83
361-01VA-NSNSChallenger - DC Voltmeter1-1/220 Volts20 Volts1.8 x 2.3 x 1.8
362-01VA-NSNSChallenger - DC Voltmeter2-1/220 Volts20 Volts2.66 x 3.12 x 1.81
363-01VA-NSNSChallenger - DC Voltmeter3-1/220 Volts20 Volts3.32 x 3.89 x 1.83
364-01VA-NSNSChallenger - DC Voltmeter4-1/220 Volts20 Volts4.18 x 4.73 x 1.83
361-01VA-KAKAChallenger - DC Millivoltmeter1-1/2200 mV200 mV1.8 x 2.3 x 1.8
362-01VA-KAKAChallenger - DC Millivoltmeter2-1/2200 mV200 mV2.66 x 3.12 x 1.81
363-01VA-KAKAChallenger - DC Millivoltmeter3-1/2200 mV200 mV3.32 x 3.89 x 1.83
364-01VA-KAKAChallenger - DC Millivoltmeter4-1/2200 mV200 mV4.18 x 4.73 x 1.83
361-01VA-RLRLChallenger - DC Voltmeter1-1/2200 Volts200 Volts1.8 x 2.3 x 1.8
362-01VA-RLRLChallenger - DC Voltmeter2-1/2200 Volts200 Volts2.66 x 3.12 x 1.81
363-01VA-RLRLChallenger - DC Voltmeter3-1/2200 Volts200 Volts3.32 x 3.89 x 1.83
364-01VA-RLRLChallenger - DC Voltmeter4-1/2200 Volts200 Volts4.18 x 4.73 x 1.83
361-01VA-RSRSChallenger - DC Voltmeter1-1/2250 Volts250 Volts1.8 x 2.3 x 1.8
362-01VA-RSRSChallenger - DC Voltmeter2-1/2250 Volts250 Volts2.66 x 3.12 x 1.81
363-01VA-RSRSChallenger - DC Voltmeter3-1/2250 Volts250 Volts3.32 x 3.89 x 1.83
364-01VA-RSRSChallenger - DC Voltmeter4-1/2250 Volts250 Volts4.18 x 4.73 x 1.83
361-01NA-NJNJChallenger - DC Voltmeter - Zero Center1-1/225-0-25 Volts25-0-25 Volts1.8 x 2.3 x 1.8
362-01NA-NJNJChallenger - DC Voltmeter - Zero Center2-1/225-0-25 Volts25-0-25 Volts2.66 x 3.12 x 1.81
363-01NA-NJNJChallenger - DC Voltmeter - Zero Center3-1/225-0-25 Volts25-0-25 Volts3.32 x 3.89 x 1.83
364-01NA-NJNJChallenger - DC Voltmeter - Zero Center4-1/225-0-25 Volts25-0-25 Volts4.18 x 4.73 x 1.83
361-01VA-LJLJChallenger - DC Voltmeter1-1/23 Volts3 Volts1.8 x 2.3 x 1.8
362-01VA-LJLJChallenger - DC Voltmeter2-1/23 Volts3 Volts2.66 x 3.12 x 1.81
363-01VA-LJLJChallenger - DC Voltmeter3-1/23 Volts3 Volts3.32 x 3.89 x 1.83
364-01VA-LJLJChallenger - DC Voltmeter4-1/23 Volts3 Volts4.18 x 4.73 x 1.83
361-01VA-NLNLChallenger - DC Voltmeter1-1/230 Volts30 Volts1.8 x 2.3 x 1.8
362-01VA-NLNLChallenger - DC Voltmeter2-1/230 Volts30 Volts2.66 x 3.12 x 1.81
363-01VA-NLNLChallenger - DC Voltmeter3-1/230 Volts30 Volts3.32 x 3.89 x 1.83
364-01VA-NLNLChallenger - DC Voltmeter4-1/230 Volts30 Volts4.18 x 4.73 x 1.83
361-01VA-KGKGChallenger - DC Millivoltmeter1-1/2300 mV300 mV1.8 x 2.3 x 1.8
362-01VA-KGKGChallenger - DC Millivoltmeter2-1/2300 mV300 mV2.66 x 3.12 x 1.81
363-01VA-KGKGChallenger - DC Millivoltmeter3-1/2300 mV300 mV3.32 x 3.89 x 1.83
364-01VA-KGKGChallenger - DC Millivoltmeter4-1/2300 mV300 mV4.18 x 4.73 x 1.83
361-01VA-RXRXChallenger - DC Voltmeter1-1/2300 Volts300 Volts1.8 x 2.3 x 1.8
362-01VA-RXRXChallenger - DC Voltmeter2-1/2300 Volts300 Volts2.66 x 3.12 x 1.81
363-01VA-RXRXChallenger - DC Voltmeter3-1/2300 Volts300 Volts3.32 x 3.89 x 1.83
364-01VA-RXRXChallenger - DC Voltmeter4-1/2300 Volts300 Volts4.18 x 4.73 x 1.83
361-01NA-RXRXChallenger - DC Voltmeter - Zero Center1-1/2300-0-300 V300-0-300 V1.8 x 2.3 x 1.8
362-01NA-RXRXChallenger - DC Voltmeter - Zero Center2-1/2300-0-300 V300-0-300 V2.66 x 3.12 x 1.81
363-01NA-RXRXChallenger - DC Voltmeter - Zero Center3-1/2300-0-300 V300-0-300 V3.32 x 3.89 x 1.83
364-01NA-RXRXChallenger - DC Voltmeter - Zero Center4-1/2300-0-300 V300-0-300 V4.18 x 4.73 x 1.83
361-01NA-NLNLChallenger - DC Voltmeter - Zero Center1-1/230-0-30 Volts30-0-30 Volts1.8 x 2.3 x 1.8
362-01NA-NLNLChallenger - DC Voltmeter - Zero Center2-1/230-0-30 Volts30-0-30 Volts2.66 x 3.12 x 1.81
363-01NA-NLNLChallenger - DC Voltmeter - Zero Center3-1/230-0-30 Volts30-0-30 Volts3.32 x 3.89 x 1.83
364-01NA-NLNLChallenger - DC Voltmeter - Zero Center4-1/230-0-30 Volts30-0-30 Volts4.18 x 4.73 x 1.83
361-01VA-NPNPChallenger - DC Voltmeter1-1/240 Volts40 Volts1.8 x 2.3 x 1.8
362-01VA-NPNPChallenger - DC Voltmeter2-1/240 Volts40 Volts2.66 x 3.12 x 1.81
363-01VA-NPNPChallenger - DC Voltmeter3-1/240 Volts40 Volts3.32 x 3.89 x 1.83
364-01VA-NPNPChallenger - DC Voltmeter4-1/240 Volts40 Volts4.18 x 4.73 x 1.83
361-01VA-LSLSChallenger - DC Voltmeter1-1/25 Volts5 Volts1.8 x 2.3 x 1.8
362-01VA-LSLSChallenger - DC Voltmeter2-1/25 Volts5 Volts2.66 x 3.12 x 1.81
363-01VA-LSLSChallenger - DC Voltmeter3-1/25 Volts5 Volts3.32 x 3.89 x 1.83
364-01VA-LSLSChallenger - DC Voltmeter4-1/25 Volts5 Volts4.18 x 4.73 x 1.83
361-01VA-HYHYChallenger - DC Millivoltmeter1-1/250 mV50 mV1.8 x 2.3 x 1.8
362-01VA-HYHYChallenger - DC Millivoltmeter2-1/250 mV50 mV2.66 x 3.12 x 1.81
363-01VA-HYHYChallenger - DC Millivoltmeter3-1/250 mV50 mV3.32 x 3.89 x 1.83
364-01VA-HYHYChallenger - DC Millivoltmeter4-1/250 mV50 mV4.18 x 4.73 x 1.83
361-01VA-NTNTChallenger - DC Voltmeter1-1/250 Volts50 Volts1.8 x 2.3 x 1.8
362-01VA-NTNTChallenger - DC Voltmeter2-1/250 Volts50 Volts2.66 x 3.12 x 1.81
363-01VA-NTNTChallenger - DC Voltmeter3-1/250 Volts50 Volts3.32 x 3.89 x 1.83
364-01VA-NTNTChallenger - DC Voltmeter4-1/250 Volts50 Volts4.18 x 4.73 x 1.83
361-01VA-KMKMChallenger - DC Millivoltmeter1-1/2500 mV500 mV1.8 x 2.3 x 1.8
362-01VA-KMKMChallenger - DC Millivoltmeter2-1/2500 mV500 mV2.66 x 3.12 x 1.81
363-01VA-KMKMChallenger - DC Millivoltmeter3-1/2500 mV500 mV3.32 x 3.89 x 1.83
364-01VA-KMKMChallenger - DC Millivoltmeter4-1/2500 mV500 mV4.18 x 4.73 x 1.83
362-01VA-SFSFChallenger - DC Voltmeter2-1/2500 Volts500 Volts2.66 x 3.12 x 1.81
363-01VA-SFSFChallenger - DC Voltmeter3-1/2500 Volts500 Volts3.32 x 3.89 x 1.83
364-01VA-SFSFChallenger - DC Voltmeter4-1/2500 Volts500 Volts4.18 x 4.73 x 1.83
362-01NA-SFSFChallenger - DC Voltmeter - Zero Center2-1/2500-0-500 V500-0-500 V2.66 x 3.12 x 1.81
363-01NA-SFSFChallenger - DC Voltmeter - Zero Center3-1/2500-0-500 V500-0-500 V3.32 x 3.89 x 1.83
364-01NA-SFSFChallenger - DC Voltmeter - Zero Center4-1/2500-0-500 V500-0-500 V4.18 x 4.73 x 1.83
361-01NA-NTNTChallenger - DC Voltmeter - Zero Center1-1/250-0-50 Volts50-0-50 Volts1.8 x 2.3 x 1.8
362-01NA-NTNTChallenger - DC Voltmeter - Zero Center2-1/250-0-50 Volts50-0-50 Volts2.66 x 3.12 x 1.81
363-01NA-NTNTChallenger - DC Voltmeter - Zero Center3-1/250-0-50 Volts50-0-50 Volts3.32 x 3.89 x 1.83
364-01NA-NTNTChallenger - DC Voltmeter - Zero Center4-1/250-0-50 Volts50-0-50 Volts4.18 x 4.73 x 1.83
361-01NA-LSLSChallenger - DC Voltmeter - Zero Center1-1/25-0-5 Volts5-0-5 Volts1.8 x 2.3 x 1.8
362-01NA-LSLSChallenger - DC Voltmeter - Zero Center2-1/25-0-5 Volts5-0-5 Volts2.66 x 3.12 x 1.81
363-01NA-LSLSChallenger - DC Voltmeter - Zero Center3-1/25-0-5 Volts5-0-5 Volts3.32 x 3.89 x 1.83
364-01NA-LSLSChallenger - DC Voltmeter - Zero Center4-1/25-0-5 Volts5-0-5 Volts4.18 x 4.73 x 1.83
361-01VA-LWLWChallenger - DC Voltmeter1-1/26 Volts6 Volts1.8 x 2.3 x 1.8
362-01VA-LWLWChallenger - DC Voltmeter2-1/26 Volts6 Volts2.66 x 3.12 x 1.81
363-01VA-LWLWChallenger - DC Voltmeter3-1/26 Volts6 Volts3.32 x 3.89 x 1.83
364-01VA-LWLWChallenger - DC Voltmeter4-1/26 Volts6 Volts4.18 x 4.73 x 1.83
361-01VA-JCJCChallenger - DC Millivoltmeter1-1/260 mV60 mV1.8 x 2.3 x 1.8
362-01VA-JCJCChallenger - DC Millivoltmeter2-1/260 mV60 mV2.66 x 3.12 x 1.81
363-01VA-JCJCChallenger - DC Millivoltmeter3-1/260 mV60 mV3.32 x 3.89 x 1.83
364-01VA-JCJCChallenger - DC Millivoltmeter4-1/260 mV60 mV4.18 x 4.73 x 1.83
361-01VA-NWNWChallenger - DC Voltmeter1-1/260 Volts60 Volts1.8 x 2.3 x 1.8
362-01VA-NWNWChallenger - DC Voltmeter2-1/260 Volts60 Volts2.66 x 3.12 x 1.81
363-01VA-NWNWChallenger - DC Voltmeter3-1/260 Volts60 Volts3.32 x 3.89 x 1.83
364-01VA-NWNWChallenger - DC Voltmeter4-1/260 Volts60 Volts4.18 x 4.73 x 1.83
362-01VA-SJSJChallenger - DC Voltmeter2-1/2600 Volts600 Volts2.66 x 3.12 x 1.81
363-01VA-SJSJChallenger - DC Voltmeter3-1/2600 Volts600 Volts3.32 x 3.89 x 1.83
364-01VA-SJSJChallenger - DC Voltmeter4-1/2600 Volts600 Volts4.18 x 4.73 x 1.83
362-01NA-SJSJChallenger - DC Voltmeter - Zero Center2-1/2600-0-600 V600-0-600 V2.66 x 3.12 x 1.81
363-01NA-SJSJChallenger - DC Voltmeter - Zero Center3-1/2600-0-600 V600-0-600 V3.32 x 3.89 x 1.83
364-01NA-SJSJChallenger - DC Voltmeter - Zero Center4-1/2600-0-600 V600-0-600 V4.18 x 4.73 x 1.83
361-01VA-JDJDChallenger - DC Millivoltmeter1-1/275 mV75 mV1.8 x 2.3 x 1.8
362-01VA-JDJDChallenger - DC Millivoltmeter2-1/275 mV75 mV2.66 x 3.12 x 1.81
363-01VA-JDJDChallenger - DC Millivoltmeter3-1/275 mV75 mV3.32 x 3.89 x 1.83
364-01VA-JDJDChallenger - DC Millivoltmeter4-1/275 mV75 mV4.18 x 4.73 x 1.83
361-01VA-MJMJChallenger - DC Voltmeter1-1/28 Volts8 Volts1.8 x 2.3 x 1.8
362-01VA-MJMJChallenger - DC Voltmeter2-1/28 Volts8 Volts2.66 x 3.12 x 1.81
363-01VA-MJMJChallenger - DC Voltmeter3-1/28 Volts8 Volts3.32 x 3.89 x 1.83
364-01VA-MJMJChallenger - DC Voltmeter4-1/28 Volts8 Volts4.18 x 4.73 x 1.83
361-01VA-PDPDChallenger - DC Voltmeter1-1/280 Volts80 Volts1.8 x 2.3 x 1.8
362-01VA-PDPDChallenger - DC Voltmeter2-1/280 Volts80 Volts2.66 x 3.12 x 1.81
363-01VA-PDPDChallenger - DC Voltmeter3-1/280 Volts80 Volts3.32 x 3.89 x 1.83
364-01VA-PDPDChallenger - DC Voltmeter4-1/280 Volts80 Volts4.18 x 4.73 x 1.83
361-01NA-PDPDChallenger - DC Voltmeter - Zero Center1-1/280-0-80 Volts80-0-80 Volts1.8 x 2.3 x 1.8
362-01NA-PDPDChallenger - DC Voltmeter - Zero Center2-1/280-0-80 Volts80-0-80 Volts2.66 x 3.12 x 1.81
363-01NA-PDPDChallenger - DC Voltmeter - Zero Center3-1/280-0-80 Volts80-0-80 Volts3.32 x 3.89 x 1.83
Sorry, no products were found fitting that criteria. Please widen your search or reset item filters now
