AC Current Switchboard Meters – Yokogawa AB40 Replacements

Description

The Yokogawa AB series Switchboard Instruments complies with the American ANSI-C39.1 accuracy class 1 specification. Available in the 4½” case size, their rugged design characteristics meet the needs of the most demanding environment applications. Engineering know-how, based on time-proven designs and worldwide use, is built into every switchboard instrument.

  •  Rectifier Type
  •  Readable Even from Sharp Angles
  •  Accurate to Within ±1% of Full Scale
  •  Metal Case
  •  Self-Contained & Transformer-Rated Ammeters
  •  UL Recognition (optional)

Catalog Page-046

Call for Direct Replacement of Yokogawa AB-40 Analog Switchboard Series

Clear
SKU: N/A Categories: , ,
Show Advanced Filters

products found
Item # Model Type Rating Scale Case Size
103131LALAMCSSelf-Contained, 40/70 Hz1 A0-1 A4 1/4 in
103131LSSCMCSTransformer-Rated, 40/70 Hz5 A0-400 A4 1/4 in
103131LCLCMCSSelf-Contained, 40/70 Hz1.5 A0-1.5 A4 1/4 in
103131LSSFMCSTransformer-Rated, 40/70 Hz5 A0-500 A4 1/4 in
103131LELEMCSSelf-Contained, 40/70 Hz2 A0-2 A4 1/4 in
103131LSSJMCSTransformer-Rated, 40/70 Hz5 A0-600 A4 1/4 in
103131LJLJMCSSelf-Contained, 40/70 Hz3 A0-3 A4 1/4 in
103131LSSNMCSTransformer-Rated, 40/70 Hz5 A0-800 A4 1/4 in
103131LSLSMCSSelf-Contained, 40/70 Hz5 A0-5 A4 1/4 in
103131LSSSMCSTransformer-Rated, 40/70 Hz5 A0-1000 A4 1/4 in
103131MFMFMCSSelf-Contained, 40/70 Hz7.5 A0-7.5 A4 1/4 in
103131LSSVMCSTransformer-Rated, 40/70 Hz5 A0-1200 A4 1/4 in
103131MTMTMCSSelf-Contained, 40/70 Hz10 A0-10 A4 1/4 in
103131LSTCMCSTransformer-Rated, 40/70 Hz5 A0-1500 A4 1/4 in
103131NDNDMCSSelf-Contained, 40/70 Hz15 A0-15 A4 1/4 in
103131LSTMMCSTransformer-Rated, 40/70 Hz5 A0-2000 A4 1/4 in
103131NGNGMCSSelf-Contained, 40/70 Hz20 A0-20 A4 1/4 in
103131LSTVMCSTransformer-Rated, 40/70 Hz5 A0-2500 A4 1/4 in
103131NLNLMCSSelf-Contained, 40/70 Hz30 A0-30 A4 1/4 in
103131LSUAMCSTransformer-Rated, 40/70 Hz5 A0-3000 A4 1/4 in
103131LSMTMCSTransformer-Rated, 40/70 Hz5 A0-10 A4 1/4 in
103131LSUEMCSTransformer-Rated, 40/70 Hz5 A0-4000 A4 1/4 in
103131LSNDMCSTransformer-Rated, 40/70 Hz5 A0-15 A4 1/4 in
103131LSUJMCSTransformer-Rated, 40/70 Hz5 A0-5000 A4 1/4 in
103131LSNGMCSSelf-Contained, 40/70 Hz5 A0-20 A4 1/4 in
103131LSUPMCSTransformer-Rated, 40/70 Hz5 A0-6000 A4 1/4 in
103131LSNJMCSTransformer-Rated, 40/70 Hz5 A0-25 A4 1/4 in
103131LSUSMCSTransformer-Rated, 40/70 Hz5 A0-7000 A4 1/4 in
103131LSNLMCSTransformer-Rated, 40/70 Hz5 A0-30 A4 1/4 in
103131LSUWMCSTransformer-Rated, 40/70 Hz5 A0-8000 A4 1/4 in
103131LSNPMCSTransformer-Rated, 40/70 Hz5 A0-40 A4 1/4 in
103131LSNTMCSTransformer-Rated, 40/70 Hz5 A0-50 A4 1/4 in
103131LSPBMCSTransformer-Rated, 40/70 Hz5 A0-75 A4 1/4 in
103131LSPKMCSTransformer-Rated, 40/70 Hz5 A0-100 A4 1/4 in
103131LSPZMCSTransformer-Rated, 40/70 Hz5 A0-150 A4 1/4 in
103131LSRLMCSTransformer-Rated, 40/70 Hz5 A0-200 A4 1/4 in
103131LSRSMCSTransformer-Rated, 40/70 Hz5 A0-250 A4 1/4 in
103131LSRXMCSTransformer-Rated, 40/70 Hz5 A0-300 A4 1/4 in
