Accuenergy DIN Power & Energy Meters – AcuRev 1310 Series

Description

The Accuenergy AcuRev 1310 DIN Rail meter combines high performance with ease of integration to provide a cost-effective power and energy monitoring solution. Featuring a built-in LCD display designed to simplify setup and local reading of meter data. While the Modbus-RTU and pulse output communication allows seamless integration with data acquisition systems.

  • Utility Revenue Grade Accuracy – IEC 62053-22 0.5s Class / ANSI C12.20 0.5 Class
  • Multiple CT Input Options
  • 4 Channel current input including neutral current measurement
  • Residual current measurement available
  • 10-690Vac direct voltage input, fits all voltage rating system with one model
  • RS-485 port built-in with Modbus-RTU, standard integration with most systems
  • Standard Din-rail mount for ease-of-installation
  • Compatible with both 50Hz and 60Hz systems
  • Built-in energy pulse output and alarm output
  • Optional relay output for alarm and remote control
  • Tamper-proof design approved for revenue applications

Catalog Page 029C                    Accuenergy-AcuRev-1310-Datasheet

Clear
Show Advanced Filters

products found
Item # Description Current Input I/O
1311-333-X0Active Power & Energy Meter333mV input CTNo additional I/O
1312-RCT-X1Active/Reactive Power & Energy MeterRogowski coil CTRelay Output
1311-mA-X0Active Power & Energy Meter80/100/200mA input CTNo additional I/O
1313-333-X1Bi-Directional Power & Energy Meter333mV input CTRelay Output
1311-5A-X0Active Power & Energy MeterField configurable CTNo additional I/O
1313-333-X0Bi-Directional Power & Energy Meter333mV input CTNo additional I/O
1311-5A-X1Active Power & Energy MeterField configurable CTRelay Output
1313-RCT-X0Bi-Directional Power & Energy MeterRogowski coil CTNo additional I/O
1312-5A-X0Active/Reactive Power & Energy MeterField configurable CTNo additional I/O
1313-RCT-X1Bi-Directional Power & Energy MeterRogowski coil CTRelay Output
1311-RCT-X0Active Power & Energy MeterRogowski coil CTNo additional I/O
1313-mA-X1Bi-Directional Power & Energy Meter80/100/200mA input CTRelay Output
1311-RCT-X1Active Power & Energy MeterRogowski coil CTRelay Output
1313-mA-X0Bi-Directional Power & Energy Meter80/100/200mA input CTNo additional I/O
1312-5A-X1Active/Reactive Power & Energy MeterField configurable CTRelay Output
1314-5A-X1Bi-Directional Power & Energy Meter w/residual currentField configurable CTRelay Output
1311-333-X1Active Power & Energy Meter333mV input CTRelay Output
1314-5A-X0Bi-Directional Power & Energy Meter w/residual currentField configurable CTNo additional I/O
1312-333-X0Active/Reactive Power & Energy Meter333mV input CTNo additional I/O
1314-mA-X1Bi-Directional Power & Energy Meter w/residual current80/100/200mA input CTRelay Output
1311-mA-X1Active Power & Energy Meter80/100/200mA input CTRelay Output
1314-333-X0Bi-Directional Power & Energy Meter w/residual current333mV input CTNo additional I/O
1312-333-X1Active/Reactive Power & Energy Meter333mV input CTRelay Output
1314-mA-X0Bi-Directional Power & Energy Meter w/residual current80/100/200mA input CTNo additional I/O
1312-RCT-X0Active/Reactive Power & Energy MeterRogowski coil CTNo additional I/O
1314-RCT-X1Bi-Directional Power & Energy Meter w/residual currentRogowski coil CTRelay Output
1312-mA-X0Active/Reactive Power & Energy Meter80/100/200mA input CTNo additional I/O
1314-333-X1Bi-Directional Power & Energy Meter w/residual current333mV input CTRelay Output
1312-mA-X1Active/Reactive Power & Energy Meter80/100/200mA input CTRelay Output
1314-RCT-X0Bi-Directional Power & Energy Meter w/residual currentRogowski coil CTNo additional I/O
1313-5A-X0Bi-Directional Power & Energy MeterField configurable CTNo additional I/O
1313-5A-X1Bi-Directional Power & Energy MeterField configurable CTRelay Output
