600A, 1000A Clamp Meter – Extech
Description
Extech Instruments offer a variety of 600 & 1000A clamp meters customized to suit the needs of your measuring requirements. The high accuracy 4000 count (EX65x series) and 6000 count ( EX800 series) have several models to choose from. Ranges include, AC/DC amperes & voltage, Temperature, resistance, capacitance, frequency, non-contact voltage & non-contact infrared temperature.
Extech EX650: 600A True RMS AC Clamp Meter + NCV: TRMS AC Clamp Meter with Non-Contact Voltage Detector and Low Impedance. This clamp meter also measures AC/DC voltage, resistance, capacitance, continuity/diode test and has an NCV detector
Extech EX655: 600A True RMS AC/DC Clamp Meter + NCV: TRMS AC/DC Clamp Meter with Non-Contact Voltage Detector, Low Impedance, Low Pass Filter and K Temperature probe. This clamp meter also measures AC/DC voltage, resistence, capacitance, frequency, temperature, continuity/diode test and has an NCV detector
Extech EX810: 1000A AC Clamp Meter with IR Thermometer: AVG AC Clamp-on multimeter with built-in non-contact InfraRed Thermometer. Other features include AC/DC voltage, resistance, capacitance and frequency
Extech EX820: 1000A True RMS AC Clamp Meter with IR Thermometer: TRMS AC Clamp-on multimeter with built-in non-contact InfraRed Thermometer and K Temperature probe. Other functions include AC/DC voltage, resistance, Type K thermometer, capacitance and frequency.
Extech EX830: 1000A True RMS AC/DC Clamp Meter with IR Thermometer: TRMS AC/DC Clamp-on multimeter with built-in non-contact InfraRed Thermometer and K Temperature probe. In addition to AC/DC current, it measures AC/DC voltage, resistance, temperature, capacitance, and frequency. It features: diode test, audible continuity beeper, min/max, data hold, auto power-off, and a fast peak hold that captures inrush currents and transients
Catalog Page 145 EX65x_Datasheet EX8xx_Datasheet
Item # | Counts | Current | Temperature | Capacitance | Frequency |
---|---|---|---|---|---|
EX650 | 6000 | 600A AC TRMS | N/A | .01nF to 60uF | N/A |
EX820 | 4000 | 1000A AC TRMS | Non-contact IR & Type K probe | .001nF to 40,000uF | .001kHz to 4kHz |
EX830 | 4000 | 1000A AC/DC TRMS | Non-contact IR & Type K probe | .001nF to 40,000uF | .001kHz to 4kHz |
EX655 | 6000 | 600A AC/DC TRMS | Type K probe | .01nF to 60uF | 10Hz to 1MHz |
EX810 | 4000 | 1000A AC Avg | Non-contact IR | .001nF to 40,000uF | .001kHz to 4kHz |
